Nektar Impact LX Mini

• 4 velocity curves  (soft, default, hard 1, hard 2) + 3 fixed values

• Joystick for pitch bend, 2 modulation controls (MIDI assignable)

• Footswitch jack 1/8″ (adapter to 1/4″ included)

• Octave up/down buttons with LED indicators

• Transpose via Shift + Part 2 buttons

• Part 2 LED buttons (assignable to momentary keyboard shift, transpose, layering MIDI notes and switching MIDI channels (includes Latch option)

• 7 transport buttons for DAW integration or MIDI assignable

• Shift button activates secondary level for a total of 14 accessible MIDI button functions (plus 3rd level for another 7 functions with Nektar DAW Integration)

• 8 velocity-sensitive LED Pads (4 pad maps)

• 8 pots (x2 via Page button, functionality changes according to mode)

• Volume pot with LED settings indication (MIDI-assignable)

• Nektar DAW integration support*

• Nektar DAW Integration for Impact LX Mini currently supports:  Ableton Live, Bitwig, Cakewalk, Cubase, Digital Performer, FL Studio, Garageband, Logic, Nuendo, Reaper, Reason, Studio One. Includes template setup for Pro Tools.

System Requirements

• • USB class compliant (no driver needed) works with any DAW or MIDI music software for OS X, Windows and iOS (iOS requires optional Apple Camera Kit)

  • LX Mini: Windows XP, Vista, 7, 8, 10 or higher.
    Mac OS X 10.5 or higher, Linux (Ubuntu).

  • Nektar DAW Integration: Windows 7/8/10 or higher. Mac OS 10.7 or higher.


Dimensions & Weight

• • 39 cm (L) x 18,5 cm (D) x 3,8 cm (H), 1 kgs


In the box

• • Impact LX Mini USB MIDI Controller keyboard

  • User Guide

  • Micro USB cable

  • 1/8″ male jack to 1/4″ female jack cable for footswitch socket

  • Bitwig License card*
